LFile Reference Manual & Qt Playout Guide

The LFile class is the core file playout and decoding engine of the now2sdk framework, derived from the base LObject class. It is designed to read, decode, filter, format, and stream local media files (MP4, MKV, MOV, AVI, MXF, TS, etc.) or image sequences frame-by-frame (AVFrame*) synchronously to registered sinks such as LPreview, LMixer, LRecorder, or LOutput.

Under the hood, LFile is built on a highly optimized, multi-threaded FFmpeg pipeline (libavformat, libavcodec, libswresample, libavfilter).

1. Architectural Concept & Core Pipelines

graph TD
    A[Local Media File / Image Sequence] --> B[FFmpeg Demuxer - libavformat]
    B -->|Video Packets| C[Video Decoder - CPU / GPU Hardware]
    B -->|Audio Packets| D[Audio Decoder - libavcodec]

    C --> E{Bypass Mode?}
    E -->|Yes: gpu=true| H[Direct Frame Queue]
    E -->|No: gpu=false| F[FFmpeg Video Filter Graph]

    F -->|Deinterlacing: bwdif| G[Dynamic Scaling / Padding / Frame Rate conversion]
    G -->|Custom Filters: LFilter| H

    D --> I[FFmpeg Audio Filter Graph]
    I -->|Audio Delay: adelay| J[Resampler / Peak Calculator]
    J -->|Custom Filters: LFilter| K[Audio Frame Queue]

    H --> L[distributeVideoFrame]
    K --> M[distributeAudioFrame]

    L --> N[Sinks: LPreview / LMixer / LOutput / LRecorder]
    M --> N

Key Subsystems:

• Frame-Accurate Clock Synchronization: Playback timing is managed using a high-precision steady_clock. Frames are scheduled and delayed dynamically based on their presentation timestamp (PTS) and the active playbackRate.
• Direct GPU Bypass Path: Activated when gpu is set to true and no filters or output formatting properties are specified. This mode completely bypasses the CPU filter graph (scaling, padding, format conversion) for zero-copy efficiency.
• FFmpeg Video Filter Graph Builder: Dynamically builds filter chains at runtime to perform aspect-ratio conversions (letter-box, crop, or stretch), deinterlacing (bwdif), custom color spaces (ARGB32, NV12, UYVY, etc.), frame-rate adjustments, and developer-defined custom effects.
• Image Sequence Reader: Automatically detects image sequence directories if the file path contains wildcard patterns (e.g. /path/to/sequence_%04d.png), utilizing the FFmpeg image2 format driver.
• Multi-Track Audio Demuxing: Supports switching audio tracks inside container files dynamically at runtime, as well as applying individual channel delay filters (adelay) and output format normalization.

2. API Reference & Key Methods

📌 Playback Control Methods

void fileNameSet(const std::string& filePath);

Sets the path of the media file or image sequence. If the file is currently playing, it automatically stops the playback before applying the new path.

bool play();

Opens the file, initializes FFmpeg decoders, starts the internal decoding thread, and begins distributing audio/video frames. Returns true if successful.

void pause(double ms = 0);

Pauses playback. If ms is greater than 0, it configures an automatic timer to resume playback after the specified duration in milliseconds.

void resume();

Resumes paused playback.

void stop();

Stops the decoding thread, flushes all registered sinks, closes the file, and releases all decoder contexts and FFmpeg resources.

void statusGet(int& status) override;

Retrieves the player's active state. Sets status to 1 if running/playing, and 0 if stopped.

bool isPaused() const;

Checks if the player is currently paused.

bool isRunning() const;

Checks if the player's decoding thread is active.

bool isEOF() const;

Checks if the player has reached the End of File (EOF) or the specified Out point.

📌 Precision Navigation & Seek Methods

void setPos(double ms);
void PosSet(double ms); // Backward compatibility wrapper

Seeks immediately to the specified position in milliseconds. The player is automatically resumed if paused to decode the target keyframe.

double getPos();
double PosGet(); // Backward compatibility wrapper

Returns the current playhead position in milliseconds.

void setPosTC(const std::string& tc);

Seeks to a target position using a standard Timecode string ("HH:MM:SS:FF"). The position is calculated relative to the file's start timecode.

std::string getPosTC();

Returns the current playhead position formatted as a Timecode string ("HH:MM:SS:FF").

void RateSet(double rate);

Sets the playback speed rate.

• 1.0: Normal speed.
• 2.0: Fast forward (2x).
• 0.5: Slow motion (0.5x).

double RateGet();

Returns the active playback rate.

void InOutSet(double inMs, double outMs);

Restricts playback bounds. Playback will seek to inMs on start/loop and stop or loop immediately when hitting outMs.

void InOutGet(double& inMs, double& outMs, double& durationMs);

Retrieves the defined In/Out points as well as the total media duration in milliseconds.

std::string getInTC();
std::string getOutTC();

Returns the In and Out points formatted as standard Timecode strings ("HH:MM:SS:FF").

📌 Properties & Format Configurations

void setProps(const std::string& key, const std::string& value);

Sets custom properties using a key-value structure. Details of available keys are documented in Section 3.

void setAudioDelay(int ms);
void setVideoDelay(int ms);

Applies static latency offset adjustments to the audio or video output streams, enabling synchronization troubleshooting.

void setVideoFilter(LFilter* filter);
void setAudioFilter(LFilter* filter);

Binds a custom video or audio LFilter graph to be dynamically parsed and integrated into the stream processing chain.

void setVideoFormat(const videoFormatProps& props);
void getVideoFormat(videoFormatProps& props);

Configures target format normalization rules for the output video frames (e.g. forcing frame resizing or colorspace conversions).

void setAudioFormat(const audioFormatProps& props);
void getAudioFormat(audioFormatProps& props);

Configures target normalization formatting rules for audio frames (sample rate, channels, bits per sample).

📌 Metrics & Info Getters

double getDurationMs();

Returns the total duration of the media file in milliseconds.

double getFPS() override;

Returns the frame rate of the output stream. If a target video format is defined, it returns the target FPS, otherwise falls back to the source file's original FPS.

std::string getTimeCode() override;

Returns the current Timecode. Overrides the base LObject behavior by calling getPosTC().

int getWidth();
int getHeight();

Returns the original width and height of the video track in pixels.

void getAudioPeak(float& left, float& right);

Retrieves the maximum audio peak amplitude (normalized range 0.0 to 1.0) processed during the last frame decode cycle.

void resetAudioPeak();

Resets the left and right channel audio peak registers to 0.0.

3. Properties & Configuration Options

All options listed below are configured at runtime via the setProps(const std::string& key, const std::string& value) interface:

4. Qt Playout Integration Example

This example demonstrates how to integrate LFile in a Qt window. It builds a media playlist player with progress indicators, playback control buttons (Play, Pause, Stop, Seek), real-time volume calculations, and color/audio processing filters.

mainwindow.h

#pragma once

#include <QMainWindow>
#include <QTimer>
#include <QStringList>
#include "LFile.h"
#include "LPreview.h"
#include "LFilter.h"

QT_BEGIN_NAMESPACE
namespace Ui { class MainWindow; }
QT_END_NAMESPACE

class MainWindow : public QMainWindow {
    Q_OBJECT

public:
    MainWindow(QWidget *parent = nullptr);
    ~MainWindow();

private slots:
    void onPlayClicked();
    void onPauseClicked();
    void onStopClicked();
    void onSeekSliderMoved(int position);
    void updateUI();

private:
    Ui::MainWindow* ui;
    LFile*          m_lFile;
    LPreview*       m_lPreview;
    LFilter*        m_videoColorFilter;
    LFilter*        m_audioDelayFilter;
    QTimer*         m_uiTimer;
};

mainwindow.cpp

#include "`mainwindow.h`"
#include "./ui_mainwindow.h"
#include "LFormat.h"

MainWindow::MainWindow(QWidget *parent)
    : QMainWindow(parent),
      ui(new Ui::MainWindow),
      m_lFile(new LFile()),
      m_lPreview(new LPreview()),
      m_uiTimer(new QTimer(this))
{
    ui->setupUi(this);

    // 1. Initial configuration for Playout Engine
    m_lFile->fileNameSet("/home/alsaberk/Videos/commercial_break.mp4");
    m_lFile->setProps("loop", "true");
    m_lFile->setProps("eof_hold", "true");
    m_lFile->setProps("scale_type", "letter-box");
    m_lFile->setProps("scaling_quality", "4"); // Use high-quality Lanczos scaling

    // 2. Configure Normalization Targets
    videoFormatProps videoTarget;
    videoTarget.setVideoFormat = vF::HD1080_50p; // Force 1920x1080 at 50fps
    videoTarget.colorSpace = cS::fcc_UYVY;       // Target output colorspace
    m_lFile->setVideoFormat(videoTarget);

    audioFormatProps audioTarget;
    audioTarget.setAudioFormat = aF::_16B_48K_2CH; // Normalize to 16-bit PCM 48kHz Stereo
    m_lFile->setAudioFormat(audioTarget);

    // 3. Optional: Dynamic Video & Audio Processing Filters
    m_videoColorFilter = new LFilter(LFilter::Video);
    // Apply real-time brightness, contrast, and saturation adjustments
    m_videoColorFilter->setProps("eq", "brightness=1.05:contrast=1.1:saturation=1.2");
    m_lFile->setVideoFilter(m_videoColorFilter);

    m_audioDelayFilter = new LFilter(LFilter::Audio);
    // Inject a 150ms audio offset to resolve sync mismatches
    m_audioDelayFilter->setProps("adelay", "delays=150ms|150ms");
    m_lFile->setAudioFilter(m_audioDelayFilter);

    // 4. Connect Playout Engine to preview sink widget
    m_lPreview->setProps("ui_framework", "qt");
    m_lPreview->setProps("audio_meter", "true");
    m_lPreview->setProps("timecode.preview", "true");

    // Bind to the preview widget inside the Qt UI structure
    m_lPreview->previewEnable(ui->playerPreviewWidget, true, true);
    m_lPreview->previewObject(m_lFile);

    // 5. Connect UI Triggers
    connect(ui->playBtn, &QPushButton::clicked, this, &MainWindow::onPlayClicked);
    connect(ui->pauseBtn, &QPushButton::clicked, this, &MainWindow::onPauseClicked);
    connect(ui->stopBtn, &QPushButton::clicked, this, &MainWindow::onStopClicked);
    connect(ui->progressSlider, &QSlider::sliderMoved, this, &MainWindow::onSeekSliderMoved);

    // 6. Start UI refresh loop (50ms interval)
    connect(m_uiTimer, &QTimer::timeout, this, &MainWindow::updateUI);
    m_uiTimer->start(50);
}

MainWindow::~MainWindow() {
    m_lFile->stop();
    delete m_lPreview;
    delete m_videoColorFilter;
    delete m_audioDelayFilter;
    delete m_lFile;
    delete ui;
}

void MainWindow::onPlayClicked() {
    m_lFile->play();
}

void MainWindow::onPauseClicked() {
    m_lFile->pause();
}

void MainWindow::onStopClicked() {
    m_lFile->stop();
}

void MainWindow::onSeekSliderMoved(int position) {
    // Seek instantly to specified millisecond position
    m_lFile->setPos(static_cast<double>(position));
}

void MainWindow::updateUI() {
    double currentMs = m_lFile->getPos();
    double durationMs = m_lFile->getDurationMs();

    // Update Slider limits and values
    ui->progressSlider->setMaximum(static_cast<int>(durationMs));
    ui->progressSlider->setValue(static_cast<int>(currentMs));

    // Update Timecode metrics
    ui->timecodeLabel->setText(QString::fromStdString(m_lFile->getPosTC()));

    // Update VU Levels
    float peakL = 0.0f;
    float peakR = 0.0f;
    m_lFile->getAudioPeak(peakL, peakR);
    ui->vuMeterLeft->setValue(static_cast<int>(peakL * 100));
    ui->vuMeterRight->setValue(static_cast<int>(peakR * 100));
}

5. .NET Playout Integration Example (WinForms / VB.NET / C#)

This example demonstrates how to integrate LFile with C# or VB.NET using the managed Now2Media.SDK.dll wrapper inside a standard Windows Forms application.

VB.NET Example (Form1.vb)

Imports Now2Media.SDK

Public Class Form1
    Private _file As LFile
    Private _preview As LPreview

    Private Sub Form1_Load(sender As Object, e As EventArgs) Handles MyBase.Load
        ' 1. Instantiate Core SDK Objects
        _file = New LFile()
        _preview = New LPreview()

        ' 2. Enable Video Preview Control on WinForms Panel Handle (HWND)
        _preview.previewEnable(VideoPanel.Handle, True, True)

        ' 3. Route File Stream to Video Preview Control
        _preview.previewObject(_file)

        ' 4. Configure Overlay Display Options
        _preview.setProps("audio_meter", "true")
        _preview.setProps("border", "true")
        _preview.setProps("status", "program") ' Red tally border outline
        _preview.setProps("name", "WIN32 GPU PLAYOUT")

        ' 5. Select Media File and Start Playback
        _file.fileNameSet("C:\Media\video.mp4")
        _file.play()
    End Sub

    Private Sub Form1_FormClosing(sender As Object, e As FormClosingEventArgs) Handles MyBase.FormClosing
        ' Clean up unmanaged wrappers on close
        _file.stop()
        _preview.Dispose()
    End Sub
End Class

C# Example (Form1.cs)

using System;
using System.Windows.Forms;
using Now2Media.SDK;

namespace Now2SDKTest
{
    public partial class Form1 : Form
    {
        private LFile _file;
        private LPreview _preview;

        public Form1()
        {
            InitializeComponent();
        }

        private void Form1_Load(object sender, EventArgs e)
        {
            // 1. Instantiate Core SDK Objects
            _file = new LFile();
            _preview = new LPreview();

            // 2. Enable Video Preview Control on Panel Handle (HWND)
            _preview.previewEnable(VideoPanel.Handle, true, true);

            // 3. Route File Stream to Video Preview Control
            _preview.previewObject(_file);

            // 4. Configure Overlay Display Options
            _preview.setProps("audio_meter", "true");
            _preview.setProps("border", "true");
            _preview.setProps("status", "program");
            _preview.setProps("name", "WIN32 GPU PLAYOUT");

            // 5. Select Media File and Start Playback
            _file.fileNameSet(@"C:\Media\video.mp4");
            _file.play();
        }

        private void Form1_FormClosing(object sender, FormClosingEventArgs e)
        {
            _file.stop();
            _preview.Dispose();
        }
    }
}
